ClimaVision Multi Sensor
7C-SE-C72X-X

An all-in-one wall sensor supporting indoor air quality, comfort, and efficiency

ClimaVision’s suite of sensor offerings gives building owners the power of IoT-connected devices for optimal efficiency and comfort in spaces where it matters most. Measure to manage with the Multi Sensor, a high-precision CO₂, occupancy, temperature and humidity sensor that connects with the ClimaVision Smart Node to deliver data that influences equipment control. This device can be daisy chained with other sensors on the 1-wire bus to provide an extensible sensor network.

The Multi Sensor is an all-in-one sensor providing temperature, humidity, occupancy, and CO₂ to augment the ClimaVision Smart Node for Title 24 compliance. This small sensor informs air quality and occupancy-based energy sequences for optimal IAQ and efficiency.

The sensor plugs into the standard 3-wire sensor bus that Carrier offers on its nodes and stats. The modern, lowprofile design appeals to aesthetics and allows the sensor to blend in with office environments.

  • Accurate temperature readings (typical +/-0.2C)
  • Accurate humidity readings (typical +/- 2% R.H.)
  • Accurate occupancy measurement with a measuring angle of 100-degree angle and 10m distance
  • CO₂ sensitivity and accuracy meets Title 24. +/- 75 ppm at a 600 and 1000 ppm concentration
  • Proprietary 1-wire protocol to communicate with a master device such as an HIA or the Smart Node
  • Can be daisy-chained with other sensors on the 1-wire bus to provide extensible sensor network

Additional Features

  • 3-wire interface for power and communication
  • Sleek design, low-impact aesthetics
  • Factory pre-calibrated
  • Easily mounted
  • Up to 4 devices can be connected on the bus
  • Accurate temperature readings (typical +/-0.2C)
  • Accurate humidity readings (typical +/- 2% R.H.)
  • Accurate occupancy measurement with a measuring angle of 100-degree angle and 10m distance
  • CO₂ sensitivity and accuracy meets Title 24. +/- 75 ppm at a 600 and 1000 ppm concentration
  • Proprietary 1-wire protocol to communicate with a master device such as an HIA or the Smart Node
  • Can be daisy-chained with other sensors on the 1-wire bus to provide extensible sensor network

Additional Features

  • 3-wire interface for power and communication
  • Sleek design, low-impact aesthetics
  • Factory pre-calibrated
  • Easily mounted
  • Up to 4 devices can be connected on the bus
