    Refrigerant Piping Design (RPD)

    Accurate pipe sizing made simple

    Carrier’s Refrigerant Piping Design (RPD) program determines minimum pipe size required to deliver refrigerant between the compressor, condenser and evaporator within specified pressure loss limits. It also sizes vertical risers so oil entrainment is assured.

    interior hvac piping

    How Does It Work?

    Refrigerant Piping Design (RPD) calculations are based on procedures and data from the ASHRAE® Handbook – Refrigeration. It supports refrigerants R-22, R-134a and R-717 for both comfort cooling and low-temperature applications. With minimal input, users can size suction, hot gas discharge and liquid lines, as well as single and double vertical risers.

    The program automatically adjusts for system operating conditions, interpolating data for accurate results. Manual pipe size specifications can also be entered to evaluate resulting pressure drops.

    Pricing: $125 US / $160 CAN

    Key Features

    Refrigerant Piping

    Sizes piping for refrigerants R-22, R-134A, R-717

    Line Sizing

    Sizes suction, hot gas discharge and liquid lines

    Riser Sizing

    Sizes single and double vertical risers

    Units of Measure

    Operates in English or SI units

    Support

    Extensive help documentation
