Supra® Truck Refrigeration Units
Supra Range for refrigerated Trucks
Developed for distribution environments with multiple door openings, you can rely on the Supra range to meet the needs of your operation.
Solutions for distribution applications
Cooling Performance
The Supra range provides temperature control across a range of setpoints and is supported by a range of evaporators with electric fans providing constant airflow independent of engine speed.
High Capacity
Extended with three high capacity models, the Supra range is available up to 12,000 Watts. Increased airflow supports rapid temperature recovery and air management. The use of a 7 mm condenser and smaller compressor is designed to support system operation.
Robust Design
Strong composite materials and components (easy start) e are designed to support equipment operation and maintenance accessibility.
Integrating into Your Working Environment
The Supra range offers extreme flexibility for a variety of transport applications. Models are available in multi-temperature, nosemount, undermount, silent and extreme-climate versions.
Learn more about Supra Truck Refrigeration Units
Contact your local dealerView the full Supra range
Supra Specifications
| Model | Cooling Capacity (W) | Heating Capacity (W) | Airflow
(m3/hr) |
Dimensions
(H x W x D) |
Weight (kg) | Refrigerant Charge (kg) | ||||
| Road 0°C/+30°C | Road -20°C/+30°C | Standby 0°C/+30°C | Standby -20°C/+30°C | +18°C/-18°C | ||||||
| Supra 750 MT | 4870 | 3000 | 4710 | 2750 | 2940 | up to 2440 | 629 x 1823 x 888 mm | 411 | 6.2 | |
| Supra 850 MT | 4880 | 3120 | 4570 | 2790 | 2990 | up to 2612 | 629 x 1823 x 888 mm | 443 | 6.8 | |
| Supra 1150 MT | 5350 | 3320 | 5360 | 3200 | 4680 | up to 3708 | 629 x 1823 x 888 mm | 576 | 6.7 | |
| Supra 1150 MT Silent | 5350 | 3320 | 5360 | 3200 | 4680 | up to 3708 | 629 x 1823 x 888 mm | 588 | 6.7 | |
| Supra 1150U MT Silent | 5990 | 3310 | 6060 | 3230 | 4680 | up to 3776 | 725 x 1972 x 830 mm | 566 | 6.8 | |
| Supra 1250 MT | 5660 | 3290 | 5360 | 3040 | 4680 | up to 3708 | 629 x 1823 x 888 mm | 576 | 7.0 | |
| Supra 1250 MT Silent | 5660 | 3290 | 5360 | 3040 | 4680 | up to 3708 | 629 x 1823 x 888 mm | 576 | 7.0 | |
| Supra 1250 City | 10040 | 5780 | 9410 | 5570 | 4120 | 3196 | 699 x 1995 x 971 mm | 644 | 6.8 | |
| Supra 1250 MT City | 5590 | 4660 | 9340 | 5690 | 4680 | up to 3708 | 699 x 1995 x 971 mm | 593 | 7.8 | |
Supra Specifications – Undermount
| Model | Cooling Capacity (W) | Heating Capacity (W) | Airflow
(m3/hr) |
Dimensions
(H x W x D) |
Weight (kg) | Refrigerant Charge (kg) | ||||
| Road 0°C/+30°C | Road -20°C/+30°C | Standby 0°C/+30°C | Standby -20°C/+30°C | +18°C/-18°C | ||||||
| Supra 900U Silent | 9020 | 4940 | 8170 | 4340 | 3360 | 3361 | 602 x 1841 x 647 mm | 453 | 6.8 | |
| Supra 1100U Silent | 10720 | 6100 | 9740 | 5570 | 3710 | 3710 | 651 x 1972 x 725 mm | 559 | 6.8 | |
