Comfort System (CS) Virtual (Using Our Virtual Wall Hardware)
CCE CS OL H

The CS virtual course is the first in the Carrier Controls Expert Training series. This course will provide Carrier field technicians, project engineers, distributors or Carrier contractor employees skills to utilize i-Vu® Tech Tool 7.0, VVT Control Systems and VAV Control Systems.

The virtual classroom allows the learner to take up to 9 days to complete the instructor-led classroom equivalent of this 4 day course. Using video tutorials as the on demand instructor, learners will execute the workbook tasks and upload assignments using the BASU LMS, asking questions through the discussion board where a dedicated factory instructor will facilitate. For more information on the Carrier Controls Expert Program, please contact your local Carrier Controls sales representative or visit carrier.com/controls-experts.

Who should attend this training

Carrier field technicians, project engineers, distributors or Carrier contractor employees who are looking to better utilize their skills with i-Vu® Tech Tool 7.0, VVT Control Systems and VAV Control Systems.

Learning Objectives

At the conclusion of this course, each student should be able to:

• Install and use the i-Vu® Tech Tool suite proficiently
• Network fundamentals of an Open Controller network
• Install, wire and configure a VVT® System
• Install, wire and configure a VAV System

Training Methods Used

This course uses an instructor-led virtual training with extensive hands-on tasks to present the material. Student’s achievement of the learning objectives is determined by successful completion of the course, and final written exam.

Topics Covered

Addressing Controllers in an Open Controller Network

MS/TP Networks

• Check 7 Different Control Modules
• Communications Check
• Device Instance

i-Vu® Tech Tools 7.0 Installation

• Install i-Vu® Tools
• Install Apploader®
• Install Test and Balance®
• Install Alarm Notification Client®
• Copy Utilities Folder
• Login to HVACPartners.com
• Download Cumulative updates and Sal files
• Copy Sal Files into i-Vu Tools
• Submit your System Files to BAS University

Configure a Router/Link (using PuTTY®)

• Set the Routers Dip Switches
• Get PuTTY® Ready
• Change the Routers Configuration

Laptop Setup and Field Assistant® Update

• Re-address the Router
• Prepare the Computer for Communications
• Launch FA 7.0
• Install the Latest Cumulative Patches

Field Assistant®, Preparing a New Site

• Launch Field Assistant®
• Find Devices

Field Assistant® Site Setup

• Time Broadcasting
• Graphic Interface
• Scheduling
• Trends
• Reports
• Global Modify

Optimizing Downloads

• Marker or Full Source downloads
• Exporting Source Files
• Importing Source files

Apploader

• Clip the AppController

Equipment Builder®

• Create a new Folder
• Start Equipment Builder®
• Create Equipment

Add a Control Program

Commission the Program

• Configure Hardware Inputs and Output
• Manipulate a Few Values

Getting a little more familiar

• Manual Command Modstat
• Manual Command PING

RTU Open lab

• Configure RTU Open
• Change/Lock Values for simulation

RTU Open PID parameter adjustments

• Adjust PID Loops for VVT Zoning System
• Search for econ_pid-da
• Search for clg_pid_da
• Search for htg_pid_ra

VVT Bypass lab

• Configure VVT Bypass Controller
• Test and Balance

VVT Terminal Unit lab

• Configure a VVT Zone Controller
• Test and Balance

VVT Master Terminal Unit lab

• Configure Airside Linkage
• Verify Linkage is Active
• RTU Open, Verify Linkage

Air Source (AppController)

• Configure the I/O Channels
• Scheduling
• Checkout Notes and Reports
• Submit your I/O assignments

VAVB1 Zone Terminal lab

• VAVB1 Configuration
• Test and Balance
• Activate the ZS Sensor

VAVB3 Zone Terminal Unit lab

• VAVB3 Configuration
• Test and Balance

VAV Master Terminal Unit lab

• Configure VAV Airside Linkage
• Setup a Rogue Zone
• Verify Linkage is Working
• Single Point Linkage
• Submit Airside Linkage Verification

Test and Balance

• Connect Test and Balance Tool
• Running Test and Balance
• Clear Parameter Mismatches in Field Assistant®

System Touch

• Access the System Touch Setup Menu
• Change the Admin Password
• Configure Sensor Setup
• Configure Inactivity Timeout
• Discover Control Modules
• Create Group Schedules

Equipment Touch

• Attach to an Open Controller from the System Touch
• View Alarm Sources
• View Schedules
• View Trends
• Equipment Properties Menu
• View Active Alarm Buffer

Factory Reset

• Default settings

Materials needed

You will need a laptop and mouse with these requirements:

• 2 GHz processor
• 2 GB RAM (minimum 4 suggested)
• 30 Gigabyte hard drive with 2 GB disk space free
• 1 USB Port
• 1 Ethernet Port (wired network interface card (NIC))
• Internet Explorer 11/Microsoft Edge/Chrome/Firefox or Safari
• Windows 10 Pro (64 bit)
• Adobe reader installed (free download from the internet)
• An internet connection NOT on the Carrier network

You will also need the following hardware:

• i-Vu® Tech Tools (part number: USB-TKIT) with latest patches.
• CS training case or equivalent hardware

*In order to complete the lab work, students are required to have access to the needed hardware along with a laptop running the current release of the Carrier i-Vu Tech Tools and necessary cables. The Carrier "Training Case Rental Program" is not available for the virtual training course.

Hardware may be purchased through your Sales Office.
