Citimax Truck Refrigeration Units

The cool experience of cool confidence

Citimax provides a full range of refrigeration units designed for all light commercial vehicles. The specifications of the Citimax 280, 400, 500 and 700 units make it possible for you to choose the best fit according to vehicle size, ambient temperatures and type of goods.

A Citimax Unit for Every Purpose

A Comprehensive Range Tailored to Your Needs

Carrier Citimax Truck Refrigeration Unit range

Your cold chain is consistently under control

Your temperature-sensitive products must be delivered in ideal condition.

They need a stable environment during transportation with controlled temperature and the ability to maintain the integrity of the cold chain. Citimax range allows you to deliver fresh and frozen products safely and with confidence thanks to the cooling power, the high refrigeration capacity (up to 58 m³) and easy fitting for any box size.

Carrier Transicold’s Citimax Refrigeration Unit Performance

Versatility

For all applications from fresh to deep frozen goods

Pull Down

20% faster pull down

Temperature Accuracy

Your temperature set points stay within +/- 1°C.

Power and Safety

Even more power and safety for road-only application

Citimax Specifications

Model	Citimax 280	Citimax 400	Citimax 500	Citimax 700
Cooling Capacity: Road 0°C/+30°C	2700 W	4080 W	5100 W	6550 W
Cooling Capacity: Road -20°C/+30°C	1525 W	2070 W	2700 W	3490 W
Heating Capacity +18°C/-18°C	2800 W	3550 W	3600 W	4100 W
Airflow	1150 m³/hr	2000 m³/hr	2200 m³/hr	2200 m³/hr
Compressor Model	Carrier 150	Carrier 160	Carrier 160	Carrier 210
Compressor Displacement	147 cm³	161 cm³	215 cm³	215 cm³
Compressor n° of Cylinders	6	6	6	6
Refrigerant Type	R-452A	R-452A	R-404A	R-404A
Refrigerant Charge	1.15 kg	1.15 kg	2.8 kg	4.0 kg
Condenser Dimensions (W x H x D)	769 x 206 x 550 mm	870 x 214 x 550 mm	1413 x 503 x 543 mm	1413 x 503 x 543 mm
Evaporator Dimensions (W x H x D)	857 x 170 x 608 mm	1100 x 193 x 614 mm	1222 x 276 x 508 mm	1222 x 276 x 551 mm
