Danaos®

Service counter with a stylish design for high visibility

BENEFITS AT A GLANCE

Excellent merchandise presentation

  • Attractive flat glass design
  • Flexibility with secondary product placement
  • Horizontal or inclined display

Increased flexibility

  • Converts from self-service to serve-over
  • Remote and plug-in version for maximum adaptability

Simplified maintenance & everyday use

  • Lift-up or tilt-down front glass
  • High-quality, easy-to-clean materials
  • SYSTEM:

    Remote;
    Plug-in

  • TEMP. RANGE:

    0/2°C, 2/4°C, 4/6°C

  • REFRIGERANT:

    R744 (CO2), Brine

    R404, R134

  • ENERGY LABEL:

    Ecodesign-Energy-Label-E-left
Some features may not be part of the standard equipment.

Enjoy the perfect combination of tradition, innovation and stylish design

With its attractive and modern design, secondary product placement option and lift-up or tilt-down front glass, Danaos brings today’s stores versatility with classic styling. The counter provides a wide range of display possibilities for fresh products – which, as you know, is essential to business and merchandising success.

Standard Features

  • Refrigerated serve-over, self-service or convertible counter with fan-assisted air circulation
  • Ventilated, hot (BW, GW)
  • 3 display decks (mm): 750, 850, 900
  • 2 base heights (mm): 600, 700
  • Superstructure A version: top canopy 270 mm, bottom-hinged tilt-down front glass
  • Superstructure B version: top canopy 400 mm, top-hinged lift-up front glass
  • Horizontal or inclined display deck
  • Evaporators protected with cataphoresis

Accessories

  • Product dividers
  • Pricing rail
  • Cutting board, knife sheath, scale/slicer platform
  • Cabinet with pedestals
  • Terminal rail for 3rd party controller
  • LED lighting
  • Variety of RAL colors available

Dimensions (mm)

  • 2 base heights (600, 700)
  • 3 display decks (750, 850, 900)
  • Superstructure A version: top canopy 270 mm, bottom-hinged tilt-down front glass
  • Superstructure B version: top canopy 400 mm, top-hinged lift-up front glass
  • Corners (EC/IC45, EC/IC90)
Modules
Danaos A/B
63
94
125
156
188
250
Total display area (m2)
Danaos.85H A/B
0.53
0.80
1.06
1.30
1.59
2.13
Danaos.85H BW A/B** -
-
0.71
-
-
-
Danaos.85H GW A/B** -
-
0.78
-
-
-
Danaos.90H A/B 0.57
0.84
1.13
1.41
1.69
2.25
Temperature range** (°C)


3M1 (-1 /+1)

Modules
Danaos A/B
312
375
EC45
EC90
IC45
IC90
Total display area (m2)
Danaos.85H A/B
2.66
3.19
0.98
1.60
1.09
2.18
Danaos.85H BW A/B** -
-
-
-
-
-
Danaos.85H GW A/B** -
-
-
-
-
-
Danaos.90H A/B 2.81
3.38
1.04
1.70
1.16
2.32
Temperature range* (°C)
3M1 (-1 /+1), BW/GW 30 - 90°


* These temperature ranges are shown in general for the refrigerated cabinets. Loading height limitation for -1 /+1 °C: 100 mm.
Please refer to the technical manual to match the right temperature to the different versions.

** These cabinets are not within the scope of “Commission Delegated Regulation (EU) 2019/2018 supplementing Regulation (EU) 2017/1369” with regard to energy labelling of refrigerating appliances with a direct sales function.
