Carrier Pulsor Truck Refrigeration Units

Pulsor® Truck Refrigeration Units

Constant Cold Throughout the Day

Maintaining constant cold throughout your intense delivery schedule is an everyday challenge. When choosing a refrigeration unit, you need to be confident it will help you deliver goods to customers in a perfect state, everytime. With an impressively quick pull-down time and precise temperature control, Pulsor is the perfect fit for customers operating in city centers with multiple door-openings, sensitive products and multi-temperature deliveries.

carrier-pulsor-truck-trees-1200x900

High Capacity Need...

Maintaining constant cold throughout your intense delivery schedule is an everyday challenge. When choosing a refrigeration unit, you need to be confident it will help you deliver goods to customers in a perfect state, everytime. Frequent stops, multiple door openings, traffic congestion, multi-temperature goods and sensitive products – it’s hard to maintain the cold chain. To keep the temperature just right, your refrigeration unit needs to provide quick pull-down and high capacity at all times.

…Even at Idle Speed

Conventional refrigeration units depend on engine speed and reach optimum capacity at 2400 RPM. But during city deliveries, your van is operating 90% of the time at low speed (under 2400 RPM)*. This compromises refrigeration capacity and makes it even harder to maintain the right temperature for your goods.

* In a standard urban delivery cycle

Key Pulsor Features and Benefits

Cold Chain Revolution

100% cooling capacity at low engine speed. Pulsor’s unique technology gives you constant optimum capacity throughout your entire delivery cycle.

Low Cost of Ownership

20% reduction in fuel consumption during pull-down. Designed with the E-Drive technology, Pulsor achieves high levels of reliability thanks to fewer moving parts and fittings. Optimum fleet availability together with reduced maintenance and fuel consumption during pull-down phase maintain a low cost of ownership.

Ensuring Sustainability

75% improvement in containment. With a significant reduction in hoses and fittings, CO2 emissions from refrigerant leaks have been reduced to protect the environment.

Unequalled Technology

Groundbreaking E-Drive™ technology. Removing the mechanical transmissions found in belt-driven systems, E-Drive™ transforms engine power into electricity. This unique and patented solution is now available for the first time in vans.

Strong Cold Chain Features with Less Environmental Impact

Fast pull-down, constant cold, wide temperatue range and precise temperature control. Pulsor is the perfect fit for customers operating in city centers with multiple door-openings, sensitive products and multi-temperature deliveries.

View the full Pulsor series

Pulsor 300


Carrier Pulsor LCV Refrigeration Unit Carrier Pulsor 300 logo

Specifications

Temperature Type: Mono Temperature

Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30° C ambient)

  MCS 600
Capacity on road at 2400rpm 0°C (W) 2 575
Capacity on road at 2400rpm -20°C (W) 1 300
Capacity on road at 1000rpm 0°C (W) 2 550
Capacity on road at 1000rpm -20°C (W) 1 300
Standby capacity* (W) 2 610
Standby capacity** (W) 1 310

Heating Capacity

Heating system (W) 1 500
Standby (W) 1 500

Airflow
(High speed engine operation)

(AMCA 21085) m3/hr 710

Weight

Road and standby condenser 91 kg
Evaporator 17 kg

Compressor

Model BS330/MS330
Displacement 32,7 cm3
n° of cylinders

Electrical Stand by Motor

Voltage / Phase / Frequency 230/1/50-60 Hz
400/3/50-60 Hz
Rating 4 500

Refrigerant

Type R-404A
Charge 1,6 kg

Sound Pressure

High speed 57 dBA

Unit

Condenser dimensions (D x W x H) 577 x 1124 x 235 mm

*Stand by capacities are given for 400 VAC version

**Stand by capacities are linked to voltage version (400 VAC or 230 VAC)

Pulsor 350


Carrier Pulsor LCV Refrigeration Unit Carrier Pulsor 350 logo

Specifications

Temperature Type: Mono Temperature

Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30° C ambient)

  MCL 850
Capacity on road at 2400rpm 0°C (W) 3 110
Capacity on road at 2400rpm -20°C (W) 1 780
Capacity on road at 1000rpm 0°C (W) 3 110
Capacity on road at 1000rpm -20°C (W) 1 780
Standby capacity* 0°c (W)

3 160

Standby capacity** -20°c (W) 1 805

Heating Capacity

Heating system (W) 2 100
Standby (W) 2 100

Airflow
(High speed engine operation)

(AMCA 21085) m3/hr 1 030

Weight

Road and standby condenser 91 kg
Evaporator 22 kg

Compressor

Model BS330/MS330
Displacement 32,7 cm3
n° of cylinders

Electrical Stand by Motor

Voltage / Phase / Frequency 230/1/50-60 Hz
400/3/50-60 Hz
Rating 4 500 W

Refrigerant

Type R-404A
Charge 1,7 kg

Sound Pressure

High speed 57 dBA

Unit

Condenser dimensions (D x W x H) 577 x 1124 x 235 mm

*Stand by capacities are given for 400 VAC version

**Stand by capacities are linked to voltage version (400 VAC or 230 VAC)

Pulsor 400


Carrier Pulsor LCV Refrigeration Unit Carrier Pulsor 400 logo

Specifications

Temperature Type: Mono Temperature

Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30° C ambient)

  MCL 1100
Capacity on road at 2400rpm 0°C (W) 3 575
Capacity on road at 2400rpm -20°C (W) 1 930
Capacity on road at 1000rpm 0°C (W) 3 420
Capacity on road at 1000rpm -20°C (W) 1 930
Standby capacity* (W) 3 615
Standby capacity** (W) 1 920

Heating Capacity

Heating system (W) 3 000
Standby (W) 3 000

Airflow
(High speed engine operation)

(AMCA 21085) m3/hr 1 580

Weight

Road and standby condenser 91 kg
Evaporator 30 kg

Compressor

Model BS330/MS330
Displacement 32,7 cm3
n° of cylinders

Electrical Stand by Motor

Voltage / Phase / Frequency 230/1/50-60 Hz
400/3/50-60 Hz
Rating 5 250 W

Refrigerant

Type R-404A
Charge 1,8 kg

Sound Pressure

High speed 57 dBA

Unit

Condenser dimensions (D x W x H) 577 x 1124 x 235 mm

*Stand by capacities are given for 400 VAC version

**Stand by capacities are linked to voltage version (400 VAC or 230 VAC)

Pulsor 400 MT


Carrier Pulsor LCV Refrigeration Unit Carrier Pulsor 400 MT logo

Specifications

Temperature Type: Multi-Temperature

Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30°C ambient)

  MCL 850 MCV 850 MCS 600
Nominal capacity (-20°C/30°C)  (W) 1 930 1 930 1 930
Capacity on road at 2400rpm 0°C (W)
3 115 2 810 2 525
Capacity on road at 2400rpm -20°C (W)
1 785 1 560 1 260
Capacity on road at 1000rpm 0°C (W)
3 115 2 810 2 525
Capacity on road at 1000rpm -20°C (W)
1 785 1 560 1 260
Standby capacity* (W)
3 160 2 780 2 580
Standby capacity** (W)
1 805 1 570 1 275

Heating Capacity

Heating system (W)
2 100 2 100 1 500
Standby (W)
2 100 2 100 1 500

Airflow
(High speed engine operation)

(AMCA 21085) m3/hr 1 030 1 015 695

Weight

Road and standby condenser 91 kg
Evaporator MCL850 22 kg
Evaporator MCV850 19 kg
Evaporator MCS600 17 kg

Compressor

Model BS330/MS330
Displacement 32,7 cm3
n° of cylinders

Electrical Stand by Motor

Voltage / Phase / Frequency 230/1/50-60 Hz
400/3/50-60 Hz
Rating Depending on configuration

Refrigerant

Type R-404A
Charge Depending on configuration

Sound Pressure

High speed 57 dBA

Unit

Condenser dimensions (D x W x H) 577 x 1124 x 235 mm

*Stand by capacities are linked to voltage version (400 VAC or 230 VAC)

**Stand by capacities are given for 400 VAC version

Pulsor 500


Carrier Pulsor LCV Refrigeration Unit Carrier Pulsor 500 logo

Specifications

Temperature Type: Mono Temperature

Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30° C ambient)

Capacity on road at 2400rpm 0°C (W) 3 930
Capacity on road at 2400 rpm -20°C (W) 2 165
Capacity on road at 1000 rpm 0°C (W) 3 930
Capacity on road at 1000 rpm -20°C (W) 2 165
Standby capacity* (W) 3 985
Standby capacity** (W) 2 180

Heating Capacity

Heating system (W) 3 000
Standby (W) 3 000

Airflow
(High speed engine operation)

(AMCA 21085) m3/hr 1 490

Weight

Road and standby condenser 130 kg

Compressor

Model BS330/MS330
Displacement 32,7 cm3
n° of cylinders

Electrical Stand by Motor

Voltage / Phase / Frequency 230/1/50-60 Hz
400/3/50-60 Hz
Rating 3 340 (W)

Refrigerant

Type R-404A
Charge 1,8 kg

Sound Pressure

High speed 57 dBA

Unit

Condenser dimensions (D x W x H) 579 x 1124 x 353 mm

*Stand by capacities are given for 400 VAC version

**Stand by capacities are linked to voltage version (400 VAC or 230 VAC)

Pulsor 600 MT


Carrier Pulsor LCV Refrigeration Unit Carrier Pulsor 600 MT logo

Specifications

Temperature Type: Multi-Temperature

Refrigeration Capacity
(System net cooling capacity under A.T.P. Conditions at 30° C ambient)

  MCL 1100 MCL 850 MCS 600
Nominal capacity (-20°C/30°C)  (W) 2 375 2 375 2 375
Capacity on road at 2400 rpm 0°C (W) 3 930 3 390 2 725
Capacity on road at 2400 rpm -20°C (W) 2 170 1 930 1 575
Capacity on road at 1000 rpm 0°C (W) 3 930 3 390 2 725
Capacity on road at 1000 rpm -20°C (W) 2 170 1 930 1 575
Standby capacity (W) 3 985 3 450 2 755
Standby capacity (W) 2 180 1 950 1 585

Heating Capacity

Heating system (W) 3 000 2 100 1 500
Standby (W) 3 000 2 100 1 500

Airflow
(High speed engine operation)

(AMCA 21085) m3/hr 1 490 1 015 695

Weight

Road and standby condenser 98 kg
Evaporator MCL1100 30 kg
Evaporator MCL850 22 kg
Evaporator MCS600 17 kg

Compressor

Model BS330/MS330
Displacement 32,7 cm3
n° of cylinders

Electrical Stand by Motor

Voltage / Phase / Frequency 400/3/50-60 Hz
Rating Depending on configuration

Refrigerant

Type R-404A
Charge 2,1 kg

Sound Pressure

High speed 57dBA

Unit

Condenser dimensions (D x W x H) 579 x 1289 x 353 mm
