AquaEdge
23XRV

High-Efficiency Variable Speed Screw Chiller with Greenspeed® Intelligence


The 23XRV chiller is the world’s first integrated variable speed, water cooled, screw chiller. The 23XRV incorporates significant breakthroughs in water-cooled chiller technology to provide excellent reliability and achieve superior efficiencies at true operating conditions without compromising the environment. Quality design and construction make the AquaEdge® 23XRV chillers the best choice for modern, efficient chilled water plants.


Carrier's AquaEdge® chillers offer the best value in high-efficiency chlorine-free variable speed screw HVAC chillers.

Performance Features

  • IPLV to 0.299
  • Chlorine-free HFC-134a refrigerant
  • Full Load kW/Ton to 0.53
  • Tri-rotor, positive displacement screw compressor
  • Hermetic compressor motor
  • Refrigerant-cooled, unit-mounted variable frequency drive
  • Low inrush current
  • Operation of up to 0.99 power factor
  • Flooded shell-and-tube cooler
  • Float valve
  • Superior oil management/cold condenser water operation
  • Internally and externally enhanced 0.025 in. (0.635 mm) copper tubing
  • 150 psig (1034 kPa) rated cooler and condenser
  • LCD control display
  • Microprocessor-based Product Integrated Control (PIC) III
  • Multilingual display
  • Demand limiting capability with Carrier Comfort Network® (CCN) communication link

Product Features

  • ASME constructed heat exchangers
  • PED/CE construction option
  • Low voltage control circuits
  • Lowest industry refrigerant leakage rate at less than 0.1%
  • Hermetically sealed compressor motor
  • Automated controls may be tested before start-up
  • 65K AIC circuit breaker

Maintenance Features

  • Password protected extensive service menu with built-in diagnostic capabilities, troubleshooting, and corrective action recommendations for preset alarms
  • Alarm and alert files maintain the last 25 time and date stamped messages in memory
  • Configuration data backup with non-volatile memory
  • Refrigerant filter isolation valves
  • Thermistor type temperature sensor with quick connects in each water nozzle
  • Service contract available

Installation Features

  • Modular construction
  • Single point electrical connection
  • Can be dismantled and reassembled
  • Unit-mounted VFD with single point connection
  • Small footprint

Standard Warranty

  • One year from start-up or 18 months from shipment

Factory-Installed Options

  • Enhanced tubing, .028 or .035 in. (0.711 or 0.889 mm): Internally/externally enhanced copper tubing - cooler/condenser
  • Internally/externally enhanced cupronickel tubing - condenser
  • Smooth bore/externally enhanced copper tubing - cooler/condenser
  • Smooth bore/externally enhanced cupronickel tubing - condenser
  • Wall tubes, titanium, condenser, .025 or .028 in. (0.635 or 0.711 mm):
  • Internally enhanced tubes
  • Smooth bore tubes
  • Marine waterboxes (available for heat exchanger frames 3-5 only):
  • 150 psig (1034 kPa) waterbox
  • 300 psig (2068 kPa) waterbox
  • Nozzle-in-head waterbox, 300 psig (2068 kPa)
  • Hinged waterboxes
  • Flanged cooler and/or condenser waterbox nozzles
  • One, 2, or 3 pass cooler or condenser waterside construction
  • Zinc anodes
  • 100K AIC high interrupt circuit breaker with shunt trip
  • Analog voltmeter and ammeter with 3-phase selector switch
  • DataLINK™ or DataPort™ communication device
  • Shipped factory charged with refrigerant
  • Hot gas bypass
  • Full cold surface thermal insulation (except waterbox covers)
  • Customer factory performance testing
  • Export crating

Field-Installed Options

  • BACnet™ Carrier translator
  • DataLINK™ or DataPort™ communication device
  • LonWorks® Carrier translator
  • Sensor package
  • Separate storage tank and pumpout unit
  • Stand-alone pumpout unit
  • Soleplate package
  • Spring isolator kit
  • Refrigerant isolation valves for in-chiller refrigerant storage
  • Unit-mounted pumpout unit for storing refrigerant inside the chiller during servicing
  • Acoustical sound insulation kit
  • Shipped fully charged
