Vector 1550
Vector 1550
The best choice for fuel efficiency, it combines the reliability of E-drive™ all-electric technology with a low-consumption engine.
Benefits:
- Protecting cargo
- Maximizing uptime
- Ensuring sustainability
- Versatility
Versatility and optimized cost of ownership for long haul deliveries and distribution assignments requiring frequent door openings.
MISSION
Your mission requires long haul temperature controlled transport and distribution with frequent door openings?
SOLUTION
The Vector 1550 unit combines efficient patented E-Drive technology with an economizer. It is ready to handle a wide range of logistical challenges with low cost of ownership and a balanced capacity of 14 700 Watts.
TECHNOLOGY
The Vector 1550 unit is equipped with patented E-Drive technology. Benefiting from the economizer capacity boost, the hermetic compressor has been downsized enabling a reduction in engine size.
BENEFITS
- Protecting cargo
- Maximizing uptime
- Ensuring sustainability
- Versatility
| COOLING CAPACITY | Nominal capacity | |
|---|---|---|
|
Diesel - Very High Speed
|
0°C/30°C
|
-
|
|
-20°C/30°C
|
-
|
|
|
Diesel - High Speed
|
0°C/30°C
|
15340 W
|
|
-20°C/30°C
|
8280 W
|
|
|
Diesel - Low Speed
|
0°C/30°C
|
12230 W
|
|
-20°C/30°C
|
6920 W
|
|
|
Diesel - Very Low Speed
|
0°C/30°C
|
-
|
|
-20°C/30°C
|
-
|
|
|
Standby - 400V/3/50 Hz
|
0°C/30°C
|
12990 W
|
|
-20°C/30°C
|
7240 W
|
| HEATING CAPACITY | ||
|---|---|---|
|
Diesel
|
8500 W
|
|
|
Standby - 400V/3/50 Hz
|
5000 W
|
| AIRFLOW | ||
|---|---|---|
|
Diesel
|
5600 m3/h
|
|
|
400V/3/50Hz
|
4600 m3/h
|
| ATP COMPLIANT | ||
|---|---|---|
|
-
|
M1027
|
| WEIGHT | ||
|---|---|---|
|
-
|
706 kg
|
| DIMENSIONS | ||
|---|---|---|
|
Height
|
2227 mm
|
|
|
Width
|
2050 mm
|
|
|
Depth
|
430 mm
|
| BOX SIZE RECOMMENDATION | ||
|---|---|---|
|
+0°C
|
+30°C
|
90 m3
|
|
+40°C
|
90 m3
|
|
|
-20°C
|
+30°C
|
90 m3
|
|
+40°C
|
90 m3
|
| SOUND EMISSION | ||
|---|---|---|
|
Sound Power
|
Power Lwa
|
98 dB
|
|
Diesel - High Speed
|
Pressure
|
71.5 dB
|
|
Diesel - Low Speed
|
Pressure
|
67.4 dB
|
|
Standby - 400V/3/50 Hz
|
Pressure
|
62.6 dB
|
| COMPONENTS | ||
|---|---|---|
|
Engine
|
Displacement
|
1498 cc
|
|
# cylinders
|
4
|
|
|
Compressor
|
Techno
|
Scroll
|
|
Model
|
ZF19
|
|
|
Controls
|
Logicold
|
| REFRIGERANT | ||
|---|---|---|
|
Refrigerant
|
Type
|
R452A
|
|
Charge
|
5 kg
|
