Supra City 1250
Supra City 1250
Quiet solution (Piek Certified) for all your distribution needs
SUPRA City for extreme low noise performance for refrigerated trucks
BENEFITS
- Constant evaporator airflow
- Robust design
- High reliability
- Extreme low-noise capabilities
- High cooling performance
SUPRA 1250 City is the quiet solution (Piek Certified) for all your distribution needs. It offers a total flexibility for multi-product deliveries with ultra-slim evaporators that can be adapted to large configuration requirement.
Developed for distribution environments with multiple doors openings, rely on the unmatched performance of the SUPRA range in your challenging operation.
The SUPRA range achieves superior pull-down and accurate temperature control at all set points. This performance is supported by a large range of evaporators with electric fans providing constant airflow independent of engine speed.
BENEFITS
- Constant evaporator airflow
- Robust design
- High reliability
- Extreme low-noise capabilities
- High cooling performance
| COOLING CAPACITY | Nominal | |
|---|---|---|
|
Diesel - High Speed
|
0°C/30°C
|
9540 W
|
|
-20°C/30°C
|
5420 W
|
|
|
Diesel - Low Speed
|
0°C/30°C
|
7100 W
|
|
-20°C/30°C
|
4660 W
|
|
|
Standby - 400V/3/50 Hz
|
0°C/30°C
|
8640 W
|
|
-20°C/30°C
|
4820 W
|
| HEATING CAPACITY | ||
|---|---|---|
|
Diesel
|
4120 W
|
|
|
Standby - 400V/3/50 Hz
|
2350 W
|
| AIRFLOW | ||
|---|---|---|
|
Diesel
|
3222 m3/h
|
| ATP COMPLIANT | ||
|---|---|---|
|
-
|
M981
|
| WEIGHT | ||
|---|---|---|
|
-
|
644 kg
|
| DIMENSIONS | ||
|---|---|---|
|
Height
|
699 mm
|
|
|
Width
|
1995 mm
|
|
|
Depth
|
971 mm
|
| BOX SIZE RECOMMENDATION | ||
|---|---|---|
|
+0°C
|
+30°C
|
80 m3
|
|
+40°C
|
64 m3
|
|
|
-20°C
|
+30°C
|
59 m3
|
|
+40°C
|
49 m3
|
| SOUND EMISSION | ||
|---|---|---|
|
Sound Power
|
Power Lwa
|
92 dB
|
|
Diesel - High Speed
|
Pressure
|
63.8 dB
|
|
Diesel - Low Speed
|
Pressure
|
58.4 dB
|
|
Standby - 400V/3/50 Hz
|
Pressure
|
58.6 dB
|
|
Piek compliant
|
<60 dB
|
Yes
|
| COMPONENTS | ||
|---|---|---|
|
Engine
|
Displacement
|
1123 cc
|
|
# cylinders
|
3
|
|
|
Motor
|
Voltage
|
400V/3/50Hz
|
|
Power
|
9 kW
|
|
|
Compressor
|
Techno
|
Reciprocating
|
|
Model
|
O5G
|
|
|
Controls
|
EasyCold
|
| REFRIGERANT | ||
|---|---|---|
|
Refrigerant
|
Type
|
R452A
|
|
Charge
|
6.8 kg
|
