Carrier OptiClean™ Dual-Mode Air Scrubber & Negative Air Machine
FN1AAF

600 - 1500 CFM

The Carrier OptiClean™ rolls easily into any room and plugs into a standard electrical outlet to quickly improve indoor air quality (IAQ) in schools, dental offices, hospitals, and other commercial facilities. It can be operated in two modes:

Air Scrubber—uses 99.97% efficient, long-life (~40,000 hour) HEPA filters to remove particles as small as 0.3 microns, then discharge cleaner air back into the room. Ideal for a wide range of commercial applications, including K–12 classrooms, dental office exam rooms and open-air, temporary medical facilities.

Negative Air Machine—helps convert normal hospital rooms into negative-pressure airborne infectious isolation rooms (AIIR) by adding a vacuum effect to the HEPA filtration capability. Designed to ASHRAE Standard 170 for Ventilation of Health Care Facilities.

The units can be operate either vertically or horizontally in both modes.

Find an Expert


carrier-c-ul-us

Product Highlights

  • 99.97% efficient, long-life HEPA filter removes particles as small as 0.3 microns
  • Standard MERV 7 or higher pre-filter
  • Minimum 200 CFM, maximum 1500 CFM
  • Meets or exceeds the ASHRAE Standard 170: Ventilation of Health Care Facilities
  • HEPA filter rack and sealing design meet air leakage requirement
  • Vertical design for smaller footprint compared to many competitors and can be mounted and operated horizontally when necessary
  • Portable and adaptable to nearly any appropriately-sized location
  • Heavy-duty, lockable casters for easy transport
  • Red lighted indicator to alert user when filters are overloaded (generally means pre-filter requires replacement)
  • Green on/off switch illuminates to verify when running
  • 3-second motor start delay
  • 3-speed selector switch on 006 and 015 models for various air flow ranges
  • 10-foot long power cord with strain relief
  • Exhaust transition plate to standard 10-inch round (005/006 sizes) or 12-inch oval (015 size) duct included
  • Galvanized steel, pre-painted cabinet is fully insulated
  • 115V
  • UL® listed
  • One-year limited warranty

Additional Product Details

Pre-Installed Filters
  • The Carrier OptiClean™ ships with two filters pre-installed for your convenience: a minimum MERV 7 pre-filter and a HEPA filter
    • The minimum MERV 7 pre-filter recommended replacement is 60-90 days and should be available locally*
    • The long-life HEPA filter provides approximately 40,000 hours of operation, or four years, under normal operation and maintenance*
Multi-Function Control Panel
  • On/Off Switch – A green on/off switch illuminates when the unit is on and operating
  • Filter Alert – A red light illuminates when it is time to check and/or replace one or both of the unit’s filters
  • Pressure Indicator – Compares room/ambient pressure versus internal pressure on the back side of the HEPA filter. Sets off the red indicator light when the filters are dirty
  • Three-Speed Selector Switch – Allows for low-medium-high air flow ranges
Additional Features
  • Locking casters and round duct transition assembly are shipped with every unit
  • Optional Air Diffuser Kit, sold separately, helps redirect air flow and reduces sound levels up to two decibels (air scrubber applications only)
  • Check with your equipment distributor for details
Limited Warranty
  • The Carrier OptiClean Dual-Mode Negative Air Machine and Air Scrubber are covered by a one-year parts limited warranty. See limited warranty certificate for complete details and restrictions.

*Applies to negative air machine applications only. Filter life in air scrubber applications would be reduced.

Basic Dimensional Data

Model Size Dimensions - inches (mm) Unit Operating Weight - lbs (kg)
Height* Width Depth
005, 006
49-5/8 (1260.5) 17-5/8 (447.7) 22-1/16 (560.4) 125 (56.7)
015 53-7/16 (1357.3) 21-1/8 (536.6) 22-1/16 (560.4) 150 (68.0)

*Height without casters. Add 3-5/8” (92.1 mm) when casters are installed.

Specifications

  005, 006 Size 015 Size
Air Discharge Vertical Vertical
Air Intake Dimension (thru bottom) - in. (mm) 15-1/2 x 19-13/16 (387 x 503) 19 x 19-13/16 (483 x 503)
Blower Type Direct Drive Direct Drive
CFM (Nominal) 500 500 / 1000 / 1500
Motor Type ECM ECM
Motor HP 3/4 1.0
Rated RPM 1500 1500
Factory Installed Filters (in.) Pre-Filter: 16 x 20 x 2 | HEPA: 16 x 20 x 12 Pre-Filter: 20 x 20 x 2 | HEPA: 20 x 20 x 12
Voltage 115 115
Hertz 60 60
Amps 5.0 12.0
